Spesifikasi

Input Voltage (V) : AC220V ± 15% Frequency (Hz) : 50/60 Rated Input (A) MMA/TIG : 6.2 No-Load Voltage (V) : 56 Output Current Range (A) : 10-250 Rated Output Voltage (V) MMA/TIG : 19.2 Arc force (A) : – Duty Cycle (%) : 60 No-Load Loss (W) : 60 Arc ignition : HF Efficiency (%) : 80 Power Factor : 0.73 Insulation Grade : F Housing Protection Grade : IP21 Net Weight (Kg) : 6.8 Dimension (mm) : 440260335

Description

1. Mosfet inverter circuit,high frequency arc starting
2. TIG & MMA Function
3. Automatic compensation for voltage fluctuation, can work againt input voltage fluctuation (V±15%)
4. small splashing , great penetration , easy and simple to operate and aesthetic appearance of weld seam
5. compact , portable , highly effective , low power consumption
