Spesifikasi

Input Voltage (V) : AC380V ± 15% Frequency (Hz) : 50/60 Rated Input (A) : 44 No-Load Voltage (V) : 320 Output Current Range (A) : 30-160 Rated Output Voltage (V) : 144 Duty Cycle (%) : 60 No-Load Loss (W) : 80 Arc Ignition : No Contact Efficiency (%) : 85 Power Factor : 0.93 Insulation Grade : F Housing Protection Grade : IP21 Air Pressure (Kg) : 4-6 Cutting Tickhness (mm) : 0.5-55 Net Weight (Kg) : 25 Dimension (mm) : 670337617

Description Features

1. 2T/4T
2. Post gas 0-20 seconds
3. Over heating and over current indicators
4. The default phase indicator (the machine uses 3phase, this machine can detect if the 3phase leg is unbalanced / one of them dies then the light will turn on)
5. Less pressure indicator (if the compressor wind pressure is not enough then the indicator light will turn on)
6. There is a remote CNC socket
