FLUKE 317 Clamp Meters

Fitur utama

The two models are economic, compact and offer a range of special features:

Unique 40A high-precision low current measurement--0.01A high-resolution, 1.6% high-precision measurement

The clamps are slim, lightweight, and portable, making them ideal for use in small, confined spaces

The large backlight display facilitates readings in dark environments

Starting current (inrush) functionality (319) allows measurement of the starting current of electrical and lighting equipment, for example. (319)

Current frequency measurement

Precision down to 0.01A and 0.1V

1000A/600A AC/DC current measurement (319/317)

600V AC/DC voltage measurement

4000Ω resistance measurement

Continuity beeper

Auto off function enhances battery life, meaning the instrument can work when you need it screen store ‘hold’ function for capturing a measurement result on the screen

The Fluke 317 and 319 are designed with ergonomic concepts, shaped to fit your hand and to access tight spots easily. These small and rugged clamp meters are ideally suited for current measurements up to 1000 A (319) in tight cable compartments. The Fluke 317and 319 also offer AC/DC current measurements and has a higher resolution for loads below 40 A. In addition to a compact package with a strong feature set, the Fluke 319 also equip with In-rush current and Frequency functions for testing motors, lighting, etc.

General specifications

Digital display 6000 count resolution

Low battery Indication Displays a signal when the batteries are below their required voltage

Power source Three AAA IEC LR03 batteries

Clamp opening size 1.45 in (37 mm)

Jaw diameter 1.45 in (37 mm)

Dimensions (L x W x H) 9.21 in x 2.95 in x 1.37 in

(234.0 mm x 75.0 mm x 34.8 mm)

Weight Approximately 13.5 oz (384 g) (batteries included)

Auto range Available in Ohms

Safety CE

EN/IEC 61010-1 and IEC 61010-2-032

Measurement Category: 600V CAT III

317 Electrical specifications

Current AC Range 40.00 A, 600.0 A

Resolution 0.01 A, 0.1 A

Accuracy 1.6% ±6 digit (50-60 Hz) {40 A}

2.5% ±8 digit (60-500 Hz) {40 A}

1.5% ±5 digit (50-60 Hz) {600 A}

2.5% ±5 digit (60-500 Hz) {600 A}

Crest Factor add 2% into spec for CF > 2 3.0 Max @ 500 A, 2.5 Max @ 600 A

AC response rms

Current DC Range 40.00 A, 600.0 A

Resolution 0.01 A, 0.1 A

Accuracy 1.6% ±6 digit (40 A)

1.5% ±5 digit (600 A)

Voltage AC Range 600.0 V

Resolution 0.1 V

Accuracy 1.5% ±5 digit (20-500Hz)

AC response rms

Voltage DC Range 600.0 V

Resolution 0.1 V

Accuracy 1% ±4 digit

Resistance Range 400.0 Ω, 4000 Ω

Resolution 0.1 Ω, 1 Ω

Accuracy 1% ±5 digit

Continuity ≤ 30 Ω

Inrush Integration time N/A

Frequency Range N/A

Accuracy N/A

Trigger Level N/A

319 Electrical specifications

Current AC Range 40.00 A, 600.0 A, 1000 A

Resolution 0.01 A, 0.1 A, 1 A

Accuracy 1.6% ±6 digit (50-60 Hz) {40 A}

2.5% ±8 digit (60-500 Hz) {40 A}

1.5% ±5 digit (50-60 Hz) {600/1000 A}

2.5% ±5 digit (60-500 Hz) {600/1000 A}

Crest Factor add 2% into spec for CF > 2 3.0 Max @ 500 A, 2.5 Max @ 600 A, 1.4 Max @ 1000 A

AC response rms

Current DC Range 40.00 A, 600.0 A, 1000 A

Resolution 0.01 A, 0.1 A, 1 A

Accuracy 1.6% ±6 digit (40 A)

1.5% ±5 digit (600/1000 A)

Voltage AC Range 600.0 V

Resolution 0.1 V

Accuracy 1.5% ±5 digit (20-500Hz)

AC response rms

Voltage DC Range 600.0 V

Resolution 0.1 V

Accuracy 1% ±4 digit

Resistance Range 400.0 Ω

4000 Ω

Resolution 0.1 Ω

1 Ω

Accuracy 1% ±5 digit

Continuity ≤ 30 Ω

Inrush Integration time 100 ms

Frequency Range 5.0 - 500.0 Hz

Accuracy 0.5% ±5 digit

Trigger Level 10 - 100 Hz ≥ 5 A, 5 - 10 Hz, 100 - 500 Hz ≥ 10 A

The accuracy specifications aply at 73 °F ±41 °F (23 °C ±5 °C)

Below 64 °F and above 82 °F (18 °C and above 28 °C) accuracy degrades at (0.1) times specification per °C.

True rms for ac V and ac A accuracy is specified from 5% to 100% of range.

Environmental specifications

Operating temperature 14°F to 122°F (-10 °C to 50 °C)

Storage temperature -40 °F to 140 °F (-40 °C to 60 °C)

Operating humidity Non-condensing (< 50 °F) (< 10 °C)

90% RH (50 °F to 86 °F) (10 °C to 30 °C)

75% RH (86 °F to 104 °F) (30 °C to 40 °C)

45% RH (104 °F to 122 °F) (40 °C to 50 °C)

(Without condensation)

Operating altitude 1 mile (2000 meters) above mean sea level

Storage altitude 7 miles (12,000 meters) above mean sea level

IP Rating IP40

Vibration requirements Random MIL-PRF-28800F Class 2, 5-500 Hz, 30 minutes per axis

Drop test requirements 3 ft (1 m) drop test, six sides, oak floor

EMI, RFI, EMC Instrument unspecified for use in EMC field ≥ 0.1 V/m

Temperature coefficients 0.1x (specified accuracy)/ °C

(<64 °F or > 82° F)

(<18 °C or > 28 °C)
