FLUKE 287 True-RMS Electronics Logging Multimeter

The Fluke 287 True-RMS Electronics Logging Multimeter with TrendCapture quickly documents design performance and graphically displays what happened. Its unique logging and graphing capabilities mean you no longer need to download logged readings to a PC to detect a trend. The Fluke 287 packs more accuracy and convenience into a handheld multimeter than ever before.

Specifications

Function

DC volts Range / resolution 50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V

Basic accuracy 0.025%

AC volts Range / resolution 50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V

Basic accuracy 0.4% (True-RMS)

DC current Range / resolution 500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A

Basic accuracy 0.05%

AC current Range / resolution 500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A

Basic accuracy 0.6% (True-RMS)

Temperature (excluding probe) Range / resolution -200.0°C to 1350.0°C (-328.0°F to 2462.0°F)

Basic accuracy 1.0%

Resistance Range / resolution 500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ, 5.0000 MΩ, 50.00 MΩ, 500.0 MΩ

Basic accuracy 0.05%

Capacitance Range / resolution 1.000 n, 10.00 nF, 100.0 nF, 1.000 μF, 10.00 μF, 100.0 μF, 1000 μF, 10.00 mF, 100 mF

Basic accuracy 1.0%

Frequency Range / resolution 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz

Basic accuracy 0.005%

Connectivity Optional infrared connector via Fluke ir3000 FC

General Specifications

Maximum voltage between any terminal and earth ground 1000 V

Battery type 6 AA alkaline batteries, IECLR6

Battery life 100 hours minimum, 200 hours in logging mode

Temperature Operating -20°C to 55°C

Storage -40°C to 60°C

Relative humidity 0 to 90% (0 t 37°C), 0 to 65% (37°C to 45°C), 0 to 45% (45°C to 55°C)

Electromagnetic compatibility EMC EN61326–1

Vibration Random vibration per MIL-PRF-28800F Class 2

Shock 1 meter drop per IEC/EN 61010–1 3rd Edition

Size (H x W x L) 22.2 x 10.2 x 6 cm (8.75 x 4.03 x 2.38 in)

Multiple on screen displays Yes

True-RMS AC bandwidth 100 kHz

dBV/dBm Yes

DC mV resolution 1 μV

Megohm range Up to 500 MΩ

Conductance 50.00 nS

Continuity beeper Yes

Battery/fuse access Yes/Yes

Elapse time clock Yes

Time of day clock Yes

Min-max-avg Yes

Peak 250 μs

Duty cycle 0.01% to 99.99%

Pulse width 0.025 ms, 0.25 ms, 2.5 ms, 1250.0 ms

Hold Yes

Isolated optical interface Yes

Auto/touch hold Yes

Reading memory Yes

Log to PC Yes

Interval/event logging Yes

Logging memory Up to 10,000 readings

Wireless connectivity (optional) Yes
