MITUTOYO VERNIER CALIPER 0-300/0.05MM 530-109

Spesifications :

• Name : VERNIER CALIPER 0-300/0.05MM 530-109

• SKU : MT0000102

• Brand : MITUTOYO

• Netto Weight : 036 KG

• Manufacturing Number : 530-109

• Dimension Unit : 14.5 X 44.5 X 2 CM

• Type : Vernier Caliper

Benefit :

• Able to measure outside diameter (OD), inside diameter (ID), depth and steps

• Small vernier face angle, 14 degrees, provides easy reading

• Lock screw for holding sliding jaw position

Features :

• Hardened stainless steel construction with satin chromefinish, for protection of caliper

• Measures outside dimension (OD), inside dimension (ID), step and depth (when depth bar is included)

• Raised sliding surfaces to help prevent defacement and wear of scale graduations

• Modest 14-degree face angle on vernier scale to improve visibility and reducing the possibility of parallax errors

• Item Depth : 64mm

• Maximum Measurement : 0-300mm

• Measurement Accuracy : +/-0.08mm

• Overall Length : 403 mm

• Range:0-300mm

• Resolution : 0.05mm

• Size Name : 0-300mm
