Fitur :

• Pulley system

• Clockwise & Counter

• Clockwise revolution

Spesifikasi :

• Main Motor (kW / V / Ph) : 1.5 / 380 / 3

• Max. Drilling Capacity (mm) : 32

• Max. Tapping Capacity (Metric) : M16

• Max. Face Mill Capacity (mm) : 76

• Max. End Mill Capacity (mm) : 20

• Diamete r of Column (mm) : 115

• Spindle Drive : Pulley

• Swing (mm) : 340

• Spindle Stroke (mm) : 130

• Longitudinal Travel (mm): 430

• Cross Travel (mm) : 185

• Spindle Speed Step : 6 < li>Distance Spindle Axis to Column Surface (mm) : 200

• Max. Distance Spindle Nose to Table (mm) : 330

• Spindle Taper (MT) : MT3

• Spindle Speed (rpm) : 125 ~ 2500

• Working Area of Table (mm) : 730x 210

• Center Between T-Slot Table (mm) : 45

• T-Slot Table Size(m m) : 16

• Working Area of Base (mm) : 250 x 250

• Dimension (L x W x H) (mm) : 960 x 1120 x 1710

• Weight (kg) : 270
