Spesifikasi

Input Voltage (V) : AC220V±15% Frequency (Hz) : 50/60 Rated Input Current (A) : 26 No-Load Voltage (V) : 56 Output Current Range (A) : 30-160 Rated Output Voltage (V) : 25.6 Duty Cycle (%) : 60 No-Load Loss (W) : 40 Efficiency (%) : 80 Power Factor : 0.73 Insulation Grade : F Housing Protection Grade : IP21 Net Weight (kg) : 5.75 Dimension (mm) : 350230310

Description

1. Strong ability against the power fluctuation, it can work normally under the fluctuation of ±15%;
2. Fashionable appearance, small size, light weight and easy to move;
3. Using the three-proofed structure against the dust,moisture and corrosion, very considerable protection for all the electronic components
4. Using the current PWN technology, IGBT inverter technology and also the large power diode to make sure product’s high reliability and stability.
5. With protection function for over-heat,over-current and over-voltage
6. Stable output performance,Real-time monitoring of welding power output, effective management of output current, and ensure reliability of welding.
7. With perfect ARC character, easy ARC start, stale ARC and easy control on welding carter.
8. With precise preset welding current to make sure good welding result and energy saving,more easy to operate and suitable for different thickness work-piece, thin plate in small current and thick plate in large current.
