Spindle or chuck type Jacobs Taper 6

Collet / spindle size Jacobs Taper 6

Chuck capacity 13 mm

Drilling capacity 13 mm

Reaming/Tapping capacity mm

SideToCenter_mm 22.5 mm

Free speed 600 rpm

Power 320 W

Stall torque 15.8 Nm

Length 258 mm

Free speed air consumption 10 l/s

Min. hose size 9.5 mm

Sound pressure 72.7 db(A)

Sound Power 83.7 db(A)

Vibration α (ISO-28927-5) < 2.5 m/s²

Vibration K (ISO-28927-5) 0.74 m/s²
